具有優良的耐腐蝕性能，抗油、強酸、抗強堿、強氧化劑等；具有優良的電絕緣性能、耐高電壓、高頻損耗小、不吸潮、絕緣電阻大；具有優良的耐燃、耐老化性能、耐高溫、抗衰減、傳輸穩定、使用壽命長。
應用領域：天線、電視、雷達、射頻、監控、計算機、儀器儀表等
|
型號 |
內導體 |
芯線外徑 |
編織錠數/單錠根數/直徑 |
標稱護套外徑 |
阻抗Ω |
試驗電壓KV |
|
SYV-50-2-1 |
1/0.68 |
2.2±0.10 |
16/5/0.15 |
4.0±0.2 |
50 |
3 |
|
SYV-50-2-2 |
7/0.16 |
1.5±0.10 |
16/6/0.15 |
2.8±0.2 |
50 |
3 |
|
SYV-50-3-1 |
1/0.9 |
2.95±0.13 |
16/6/0.15 |
5.0±0.2 |
50 |
3 |
|
SYV-50-3-2 |
7/0.32 |
2.95±0.13 |
24/5/0.15 |
5.0±0.2 |
50 |
3 |
|
SYV-50-5-1 |
1/1.4 |
4.8±0.20 |
24/5/0.15 |
7.2±0.3 |
50 |
5 |
|
SYV-50-5-1 |
1/1.40 |
4.8±0.20 |
24/6/0.20 |
7.2±0.3 |
50 |
5 |
|
SYV-50-7-2 |
7/0.75 |
7.25±0.25 |
24/6/0.20 |
10.3±0.3 |
50 |
8 |
|
SYV-50-9 |
7/0.95 |
9.0±0.30 |
36/5/0.2 |
12.2±0.4 |
50 |
8 |
|
SYV-50-12 |
7/1.15 |
11.5±0.30 |
36/6/0.2 |
15.0±0.4 |
50 |
8 |
|
SYV-75-4-1 |
1/0.59 |
3.7±0.13 |
16/6/0.15 |
6.0±0.2 |
75 |
3 |
|
SYV-75-4-2 |
7/0.21 |
3.7±0.13 |
16/6/0.15 |
6.07±0.2 |
75 |
3 |
|
SYV-75-5-1 |
1/0.75 |
4.8±0.20 |
24/5/0.15 |
7.2±0.2 |
75 |
5 |
|
SYV-75-5-2 |
7/0.26 |
4.8±0.20 |
24/5/0.15 |
7.2±0.2 |
75 |
5 |
|
SYV-75-7-1 |
1/1.15 |
7.25±0.15 |
24/6/0.20 |
10.3±0.3 |
75 |
8 |
|
SYV-75-7-2 |
7/0.40 |
7.25±0.25 |
24/6/0.20 |
10.3±0.3 |
75 |
8 |
|
SYV-75-9 |
1/1.37 |
9.0±0.30 |
36/5/0.20 |
12.2±0.4 |
75 |
8 |
|
SYV-75-12 |
7/0.63 |
11.5±0.30 |
36/6/0.20 |
15.0±0.4 |
75 |
8 |
